⚖️ Huami Supply Chain · Smart Production Equipment

Supply Chain Smart Weighing Scale

Name: Supply Chain Smart Weighing Scale
Brand: Huami Supply Chain
Availability: InStock

All-in-one smart weighing, auto counting, label printing, photo archive, quality control, batch management and product traceability — seamlessly integrated with ERP/MES/WMS systems

One device for the whole weighing, labeling and traceability workflow on your packing line. Every box weighed accurately, labeled correctly, traceable end-to-end.

Core Features User Guide Contact Us

Core Functions

Steps to Finish

20+

Label Fields

100%

Traceable

🎁 30-Day Free Trial 🛡️ 1-Year Warranty

Supply Chain Smart Weighing Scale - Huami

What is the Supply Chain Smart Weighing Scale?

The Smart Weighing Scale is a smart weighing & data management device designed by Huami Supply Chain for factory production lines. Powered by the Android system with a 15.6-inch HD touch screen, it integrates a high-precision weighing sensor, label/thermal printer, barcode scanner and HD camera to automate the full workflow: weigh → print label → photo archive → data upload.

Whether counting pieces for hardware & auto parts or weighing packages for food & agriculture, the scale automatically handles tare, sampling, counting and printing — eliminating manual records and hand counting, and helping factories achieve standardized packing, quality traceability and digital production management.

⚖️ High-Precision Weighing 🏷️ Auto Label Printing 📷 Photo Traceability 🔍 Scan to Verify 📊 Data Upload 🔗 ERP Integration

Core Features

Eight core function modules covering every stage of production, packing, warehousing and shipping

⚖️

Smart Weighing

High-precision weighing sensor with multiple unit conversion. Real-time weight display and out-of-tolerance alarm to ensure every box is within spec.

🔢

Auto Counting

Counts automatically by "total weight ÷ unit weight". One-touch sampling, real-time quantity display — no more manual counting errors.

🏷️

Label Printing

Thermal/adhesive label printing with product name, box quantity, batch number, date and weight. Serial numbers continue automatically.

📋

Quality Standards

Built-in product quality database displays inspection standards and tolerance ranges automatically during weighing to guide operators.

📦

Standard Packing Check

Preset standard box quantities; the scale verifies actual count automatically and alerts on overfill or shortage — zero packing errors.

📷

Photo Archive

Built-in HD camera captures product photos automatically or manually during weighing, linked to weighing data as visual quality evidence.

🔗

Batch & Traceability

Auto-generated batch numbers linked to date, line and operator. Scan the QR on any label to view the complete traceability chain — one box, one code.

🔌

ERP/MES Integration

Standard API interface uploads weighing data to ERP/MES/WMS in real time, breaking data silos from production to warehouse.

User Guide

Four simple steps from weighing to traceability — easy enough for new operators to master quickly

Scan / Select Product

Scan the product barcode or select the product name on the touch screen. The system automatically loads unit weight, tare, box spec and quality standards — no manual entry needed.

💡 Favorite products can be set as one-tap shortcut buttons

Tare → Load & Weigh

Place the empty box/container and press Tare (F4). Load products — the screen shows live weight and auto-calculated piece count. A green stable indicator confirms the reading.

💡 Container tare is memorized per batch — no repeated taring

Photo → Print Label

The system captures a product photo for archive and prints the standard packing label with batch number, date, quantity, weight and QR code in one click. Auto mode prints when the target count is reached.

💡 Auto photo on print — every box has an image record

Upload → Scan to Trace

Weighing data, photos and label info upload to the management system automatically. Customers or QC scan the QR code to view the full traceability record of any box.

💡 Real-time ERP/MES/WMS integration with auto data sync

Application Scenarios

Covering the full production chain — from workshop weighing to shipping labels — every step becomes faster and error-free

🏭

Production Line · Weigh & Count

👤 Typical users: line workers, packers

Weigh-count-label in one, batch numbers auto-generated
Products auto-identified, weighed and counted on the scale
Labels printed and applied in one smooth flow
Weighing data uploaded in real time — output at a glance
Fast product switching with preset parameters

📦

Warehouse · Scan & Weigh

👤 Typical users: warehouse staff

Automatic container tare for net weight; scan to load product
Weighing compared to order quantity with instant alarms
Every in/out record saved and searchable
Real-time inventory updates with ERP/WMS
Prevents short counts and over-shipments

📋

Packing Line · Auto Box Count

👤 Typical users: packers

Outer-box tare memorized — no repeated taring
Preset box quantities with automatic remaining-count display
Box counter accumulates; batch close alert when complete
Outer-box labels with box no., piece count and batch info
50%+ packing efficiency gain — no more hand counting

🚚

Shipping · Drag-and-Drop Labels

👤 Typical users: shipping staff

Drag-and-drop label designer — what you see is what you get
Multiple paper sizes: thermal, adhesive, A5, etc.
Reusable templates, one-click switch per customer
Print preview to avoid wasted label stock
Batch printing for multiple boxes at once

Product Traceability Solution

One box, one code, full traceability — meeting IATF 16949 quality system requirements

🏷️

Unique Trace Code

Every label carries a unique QR/barcode — scan any box to look it up

📋

Complete Records

Product name, batch, date, box quantity, net weight, operator, inspector

📷

Visual Evidence

Real photos archived per box, plus QC photos and inspection reports

🔍

Forward Tracing

From raw material batch to finished shipment — trace every step

🔄

Reverse Tracing

From a customer complaint back to material, process and operator

⚙️

System Integration

Traceability data synced to ERP/MES, aligned with quality systems

Specifications

TCS series smart scales — multiple models, customizable on request

Model	TCS-3SJ-AF01 etc. (multiple options)
Operating System	Android
Display	15.6-inch HD capacitive touch screen
Weighing Range	Customizable (3kg / 6kg / 15kg / 30kg common)
Weighing Accuracy	High-precision sensor, industrial grade
Printing	Thermal / adhesive label printing
Scanner	QR / barcode scanner
Camera	HD camera with auto photo archive
Connectivity	WiFi / 4G / Wired network
Interfaces	USB / RS232 / Ethernet / API
Label Format	Custom templates (name/batch/date/qty/weight/QR)
Power	AC 220V / 50Hz
Applications	Packing lines / warehouse in-out / QC traceability

Service Guarantee

Three service commitments — buy with confidence, use with peace of mind

🆓

7-Day Free Trial

Free trial for 7 days after delivery. Not satisfied? Hassle-free return and refund — no charge during the trial period.

🛡️

1-Year Warranty

1-year full warranty with free repair and parts replacement for non-human damage. Software lifetime free upgrades.

🤝

Lifetime Support

Dedicated 1-on-1 service with remote guidance, on-site repair and instant phone/WeChat response. Common issues answered within 2 hours.

Product Promotion Posters

Huami Supply Chain Smart Weighing Scale — smart weighing & labeling device built for factory manufacturing

Supplier shipment weighing with auto label - Smart weighing label system

AI product recognition - dual vision & weight recognition

Factory shipment anti-error system - no label if quantity wrong

Built for factory manufacturing - Smart AI weighing scale

Factory weighing anti-error - no label if quantity wrong

Regional agents wanted nationwide - factory direct supply & tech support

📞 Regional Agents Wanted — Contact Us

FAQ

Answers to the most common questions about the Smart Weighing Scale

What's the difference from a regular scale?

A regular scale only shows weight. The Smart Weighing Scale runs Android with a touch screen — it counts pieces, prints labels, archives photos, manages batches and uploads data. It's a "scale + label printer + traceability system" in one device.

Can workers who aren't computer-savvy use it?

Absolutely. Full touch operation — the main screen is simply "place product → take label → pack box". With shortcut buttons for frequent products, a new operator is productive after 10 minutes of training.

Can I design my own labels?

Yes. The built-in label designer supports drag-and-drop layout with text, tables, 6 scannable barcodes (Code128/Code39/EAN-13/EAN-8/UPC-A/QR), dates and images — bindable to 20+ data fields including product name, code, batch, net weight and quantity.

How is counting accuracy ensured?

Counting uses "total weight ÷ unit weight" with one-piece sampling. Printing is only allowed when the reading is stable, and standard packing check alerts on overfill or shortage.

Can it integrate with our existing ERP?

Yes. The device provides a standard API for ERP/MES/WMS integration: order sync, real-time weighing data return, automatic inventory records and quality standard distribution.

How does traceability work?

Every box label carries a unique QR code. Scanning it shows product name, batch, date, quantity, net weight, operator, inspector and QC photos — one box, one code, full traceability meeting IATF 16949 requirements.
